Description
| Brand | Norgren |
| ISO | – |
| Function | Single Acting and Double Acting |
| Bore | 12, 16, 20, 25, 32, 40, 50, 63, 80 and 100 mm. |
| Stroke | Ø16 – 25 Max. 200 mm. Ø32 – 40 Max. 250 mm. Ø50 – 100 Max. 300 mm. |
| Pressure | 1 To 10 bar |
| Temp. | -10˚C To 80˚C |
| Barrel | Anodized Aluminium Alloy |
| Piston Rod | Stainless Steel |
| Seal | PU and NBR |
| Cover | Anodized Aluminium Alloy |
| Magnetic Version Standard | |
Remark: Our company produces special cylinders. According to customer requirements with Accessories, Mounting Y / S / I / FA / FB / TC / U), Guide Unit, Locking Unit, Magnetic Sensor
